Over-molding

The area of over-molding floor in CFTC is about 1,000 m². Our main

products are automobile door lock latch (pawl). There are several

vertical dual rotate station injection molding machines which can

produce 28 million pcs parts per year.

CFTC will evaluate and implement automation line including

automated production, automated deburring, automated CCD

inspection, and automated packing process in the next year. With strict

discipline, CFTC is customer oriented. CFTC will continue to

produce product to fulfill customer requirement and create the value

for customer.

CFTC has the design team can design and fabricate tooling in

house.

Advantages:

1. With DFM in early tooling design stage can reduce NG

   occurrence during tooling fabrication.

2. Mold-flow simulation modeling can expedite tooling

   development.

Precision vertical dual rotate station machine

Application:

The equipment performs excellent job. It is suitable for producing automobile door lock

latch(pawl).

The injection system is MOOG+ACC hydraulic system. The thickness of plastic molding is about 0.15~0.7mm. (for precision high speed machine)

Working Principle:

Comparing the difference of magnetic field

between a good part and testing part to

determine whether the testing part has been

well heat-treated or not.

To prevent the part defect with missing

heat-treated escape to customer side. It

avoids the safety issue may be caused by

door locker.

Working Principle:

By 3D imagine scanner, it can obtain 3D

model from the reversedengineering

software.

Main Application:

1. To obtain the dimension that

   cannot measure.

2. It plays an important role on the

   quality of overmold tooling in

   earlier design stage.
